Model |
RT-R5515 |
|
Material |
PET/Aluminum Foil/Foam |
|
Dimensions |
55 x 15 x 1.25 mm（L x W x T） |
|
Working Temp |
-40~+85℃ |
|
Survive Temp |
23±3 ℃ |
|
Survival Humidity |
50±15 %RH |
|
IP Rating |
IP68,test for 5 hours at 1m deep water |
|
RFID Standard |
EPC C1G2 (ISO18000-6C) |
|
Chip Type |
Impinj Monza R6-P |
|
Memory |
User -32(64) bits; EPC – 128(96) bits; TID - 48 bits |
|
Read Range(Fixed Reader FCC) |
5.5 m, on metal; 2.8 m, in air |
|
Read Range(Fixed Reader ETSI) |
3.5 m, on metal; 2.0 m, in air |
|
Data Storage |
> 10 years |
|
Re-write |
100000 times |
|
Installation |
Adhesive |
|
Support Printer |
SATO CL4NX, Zebra ZT410 Silverline, Postek TX3r, etc. |
|
Customization |
Logo, parcoge/QR coae, number printing, encoding, antenna design, etc. |
|
Package |
Reel core inner diameter: 76.2 mm / 3" , |
|
Application |
Metallic container tracking | Equipment& device tracking |
